Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Kelsun
  • Model Number: 30104.03A
  • oscilloscope: basic oscilloscope

Packaging & Delivery

Packaging Details 2/ctn,56*43*53cm
Delivery Time 20 days



Student's oscilloscope

Art No.30104.01

1.Frequency:DC 5MHZ(≤3db)

2.Deflexion coefficiency:≤5mv/div

3.Scanning time coefficiency:10μS/div-0.1S/div

4.Triggering synchromizing:interior


6.Screen:6div*10div 1div=6mm


Oscilloscope, dual trace

Art No. 30104.02

1. Bandwidth: DC-20MHz
2. Rise time: 17.5ns
3. Input impedance: 1MΩ±5%
4. Input coupling: AC, GND, DC
5. Vertical mode: CH1, CH2, DUAL(ALT/CHOP),ADD, CH2 INV
6. Sweep rate: 0.2μs~0.5s/div ±3%
7. Trigger mode: NORM, AUTO (TV-H), TV-V, LEVEL LOCK
8. Trigger source: INT(CH1,CH2, VERT), EXT, LINE



Art No. 30104.03A

1. Frequency: DC-20MHz
2. Deflexion coefficiency: 5mV/DIV-5V/DIV,
    10 divs according to 1.2.5 order
3. Scanning time coefficiency: 0.5S/DIV-0.5μs/DIV, 20
    divs according to 1.2.5 order multiply x 10 Scanning
    speed max 50ns/DIV
4. Triggering synchronizing: Interior, alternation, source,
    outside, TV, VP auto
5. Vertical mode: CH1, CH2, ALT, CHOP, ADD
6. Scanning mode: auto,triggering
7. Size:310 x 130 x 418(mm)
8. Screen: 8 x 10DIV 1DIV=10mm



Art No. 30104.03B

1. Frequency: DC~20MHz
2. Rise time: 17.5ns
3. Sensitivity: 5mV/DIV~20V/DIV on 1-2-5 sequence 12 ranges
4. INT Triggering Source:CH1,CH2,VERT MODE,CH2
5. Sweep time: 0.2s/DIV~0.2us/DIV.19 steps in 1-2-5 sequence
6. Triggering Source: INT,EXT,LINE
8. Dimensions: 310mmx130mmx418mm
9. Display area: 8x10DIV (DIV=10mm)



Art No. 30104.04
1. Frequency: DC~40MHz
2. Rise time: ≤9.5ns
3. Deflection factor: 1mV/DIV~5V/DIV±3% 12
    calibration steps in 1-2-5 sequence
4. Vertical mode: CH1,CH2,DUAL(CHOP,ALT),ADD,CH2 inverse
5. Sweep time: 0.1us~0.1s/DIV
6. Source: ALT,CH1,CH2,EXT,LINE
8. Dimensions: 316(W)x132 (H)x10(D)mm
9. Display area: 8x10DIV (DIV=10mm)
